SHIMANO - SPHEROS SW A

SHIMANO - SPHEROS SW A

$134.99 - $184.99
Current Stock:
Adding to cart… The item has been added
Description

SPECIFICATIONS - SPHEROS SW

PRODUCT CODE MAX DRAG LINE RETRIEVE PER CRANK WEIGHT POWERPRO LINE CAPACITY GEAR RATIO MONO LINE CAPACITY BEARINGS
SP3000XGSW 20 36 9 10/200, 20/140, 40/105 6.2:1 6/230, 8/170, 10/140 3+1
SPC3000HGSW 20 35 8.6 10/200, 20/140, 40/105 6.0:1 6/230, 8/170, 10/140 3+1
SP4000XGSW 24 39 9.9 15/230, 30/180, 50/120 6.2:1 8/240, 10/200, 12/160 3+1

SPECIFICATIONS SPHEROS SW A

PRODUCT CODE MAX DRAG LINE RETRIEVE PER CRANK WEIGHT POWERPRO LINE CAPACITY GEAR RATIO MONO LINE CAPACITY BEARINGS
SPSW5000XGA 22 41 15.7 20/245, 30/225, 40/175 6.2:1 10/240, 12/195, 14/165 4+1
SPSW8000HGA 29 42 23.5 40/340, 50/265, 65/215 5.6:1 14/300, 16/250, 20/185 4+1
SPSW10000PGA 26 40 23.8 50/360, 65/290, 80/215 4.9:1 16/320, 20/220, 25/175 4+1
SPSW14000XGA 26 53 24 50/400, 65/315, 80/240 6.2:1 16/360, 20/260, 25/190 4+1
SPSW6000HGA 22 41 15.9 30/290, 50/195, 65/140 5.7:1 12/265, 16/170, 20/120 4+1
SPSW20000PGA 40 41 32.8 65/490, 80/400, 100/340 4.4:1 20/460, 25/380, 30/320 4+1
SPSW18000HGA 40 51 32.4 50/600, 65/440, 80/360 5.7:1 20/415, 25/340, 30/280 4+1

tech1
HAGANE BODY
The HAGANE Body is a metal reel body with high rigidity. The body rigidity and impact resistance virtually eliminates body flexing on the reel while fighting fish. The result transforms the angler's actions directly into cranking power, increasing efficiency through strength.

tech1
X-PROTECT
X-Protect provides high-level water resistance without sacrificing light gear and rotor rotation. By combining Shimano’s water-repellent coating with a water-channeling labyrinth construction, X-Protect provides added durability in tough conditions.

tech1
INFINITY DRIVE | SPINNING REELS
The Infinity Drive structure is an advanced structure that creates exceptionally light winding. The main shaft, which had previously been supported by the pinion gear, is now supported by a new and unique low-friction bushing that significantly decreases frictional resistance. In addition, the main shaft has undergone a proprietary surface treatment and special processing to drastically reduce rotational torque, constructing a reel that can actively wind even under heavy loads.

tech1
X-SHIP
X-Ship provides improved gear durability. By supporting the pinion gear on both ends with bearings, the pinion gear maintains precise alignment with the drive gear. This allows the gears to stay in the same position under the heaviest loads. The added benefit of X-Ship technology is that friction between the spool shaft and gear are eliminated. This further benefits anglers with enhanced casting performance and casting distance of lighter lures.

tech1
X-SHIELD
By providing dependable sealing structures and gaskets at 12 critical locations throughout the reel body, Shimano is able to create a water-resistant structure that is highly reliable and durable while ensuring that it can hold up when used in extreme saltwater conditions.

tech1
HAGANE GEAR
With amazing strength and durability, the HAGANE Gear is at the very heart of most Shimano reels. Shimano, through the application of state-of-the-art technologies, gives anglers the long-lasting smoothness and pleasure that is felt when anglers first use a reel, over and over again. No cutting work is applied to the teeth of the drive gear during fabrication, instead the entire surface is calculated in minute detail by special 3D-design and then formed by Shimano's cold-forging technology. The result is assured resilience. HAGANE Gear is the fruit of Shimano's inexhaustible pursuit for durability — the strength and power of forged metal continues to represent the fundamental concept of Shimano reels.

tech1
CROSS CARBON DRAG
The Cross Carbon Drag material provides a wider range of drag settings compared to traditional drag materials. The Cross Carbon Drag provides the smoothest Shimano drag performance ever while providing anglers with increased durability.

tech1
PROPULSION LINE MANAGEMENT SYSTEM
The most obvious component of the Propulsion Line Management System is the new Propulsion Spool Lip design. Through tens of thousands of casting tests and computer simulations, Shimano’s new spool lip design provides longer casting distances than a standard spool lip design while also preventing backlashes and wind knots from forming.
